Modo to Blender Simple Key Config

16 ratings
I want this!

Modo to Blender Simple Key Config

$0+
David Still
16 ratings

**No longer being Maintained!**  In theory, it should continue to work with newer versions of Blender tho.  You're free to use this as a reference for making your own key config and/or just use it to grab the Select-Through Lasso script that's included.  If the script were to ever stop working, it looks like this Dev has a script that does the same thing: https://gumroad.com/l/xFzti  And he will probably have the know-how to fix anything that went wrong in terms of compatibility in the future. Another person to try is: https://kjell.gumroad.com/l/kekit_blender as he has numerous Modo type features that he's put into his addon.



This is a simple keymap to make using Blender feel a bit more like Modo, while still retaining the vast majority of default Blender 2.8+ keybindings so that tutorials are still easy to follow!  It's mostly just navigation and selection changes to bring things more in line with the Modo way.

      -----------------------------------------

This is for Blender 2.80 and above! I highly doubt it will work as intended with 2.79 and below, but you are welcome to try or use this as a reference to create your own.


If you are installing on a version newer than Blender 2.80, the install will be the same except that the 2.80 part of the install file location will need to be changed to the version you are using, so the 2.81 instead of the 2.80 folder for example.

      -----------------------------------------

Some notable features are:

• Middle Mouse select through lassos

• Right Click Selecting Lassos

• Double click to select all connected Geometry

• Space bar to "drop the tool" functionality

• Modo Viewport Navigation style

• Paint Selecting while holding ctrl or shift with left click drag

• Custom Viewport Navigation Pie Menu with the buttons in the places they are in Modo

• Default render engine set to Cycles instead of Eevee to be more in line with default rendering behavior of Modo's F12 box rendering and viewport preview render. (I found myself changing it from Eevee to cycles a lot, but instructions on how to change it back + a variant with Eevee as default are included)

• Backface Culling Enabled by default

• Clip distance set as low as possible as default, so stuff doesn't get culled out of view when navigating the viewport, namely when getting very close to meshes

      -----------------------------------------

Notes:

GPU RENDERING NEEDS TO BE ENABLED FOR CYCLES IN YOUR PREFERENCES. You will need to go into Edit>Preferences>System and either enable Cuda (Nvidia GPU) or OpenCL (AMD GPU) if you want to use GPU rendering in cycles. By default, this config will only use your CPU if you don't select one or the other.

• I made this as a config instead of a keymap because as a config this will auto update itself with any new and/or changes in the official default keymap in Blender.

      -----------------------------------------

Keybinding Changes Notes:

While most of the changes are just navigation and are not worth mentioning if you have Modo muscle memory, here are some of the notable keybinding changes that you should be aware of:

• Since the WER keys had to be rebound to the move, rotate, scale tools, I rebound their default functions to be a double tap of either the E key for Extrude while in edit mode or a double tap of the R key to activate the tool handless rotate tool of blender.  I did not do this for the W key which swaps your selection method by default because it just bugged out completely when sharing the first press with the active move tool.

• A lot of the space bar key combos have been changed to make everything work while fitting in most of default blenders functionality:

    1. Space bar: Changes selection method to just be "select".  This essentially replicates Modo's drop the tool functionality.

     2. Ctrl+Space: Custom Viewport Pie Menu with buttons in the same location as the Modo one

     3. Alt+Space: Play/Pause Animation forward

     4. Ctrl+Alt+Space: Play/Pause Animation in reverse

     5. Shift+Space: Search Menu Popup underneath mouse

     6. Shift+Ctrl+Space: Active tool sidebar list popup underneath mouse

     7. Shift+Ctrl+Alt+Space: Fullscreen active viewport with UI elements on

• Moving the Cursor around had to be rebound from the default key of Shift+Right Click & Drag to Shift+Alt+Right Click & Drag because the default one obviously conflicted with the lasso select being bound to Shift+Right Click & Drag

      -----------------------------------------

Version Changes:

v1.1 - Curves, Metaballs, Armatures, Lattices, and Grease Pencil should now all have the appropriate W, E, R, spacebar, circle select, and lasso select on right click & drag keybindings bound in their respective edit modes, or as close as they can be.  They were not changed at all in the initial release.

v1.2 - Rebound moving the Cursor to be Shift+Alt+Right Click & Drag.  This means that you can properly drag the cursor around and easily snap it as you can in default blender, instead of the bad workaround I had before where you could only place it by clicking and the snapping didn't work.  Thanks to Steve White for the idea to fix it!

And the UI had changed slightly in 2.81, they added an additional toolbar at the top of the viewport.  I had to recreate the startup.blend file with the new version of blender for it to appear because the old one was created within 2.80.

v1.3 - Added in the additional keybinding for the new active tool handles in the UV Editor that were added in Blender 2.82.  This makes the WER keys in the UV Editor bring up their respective tools just like in the normal 3D views.  It's still fully compatible with 2.81 and 2.80 too.

      -----------------------------------------

Bugs:

• The active tool Box Select (The one activated in via the "T" left side bar) is basically disabled and doesn't function.  You can still activate the box selecting with the B key though.

• My paint select workaround involves temporarily activating a small circle select tool while holding down either ctrl or shift with left mouse button drag. This can sometimes cause some unwanted behavior in some very specific situations.

• While not a bug with the config I'm including, there is a reason why I am not including a Box Select instead of Lasso Select version.  There is a bug in Blender where if any form of the Box select tool with the add or deselect modifier are bound to Middle Mouse, it will not let go when you release the middle mouse.  This happens with the default tool and the original Heavy Poly Script.  This is not an issue with Lasso Select bound to Middle Mouse.


There are probably a few more quirks, but for the most part it works surprisingly well!

      -----------------------------------------

Discuss on BlenderArtist

      -----------------------------------------

Huge shout out to Brent Alleyne (@Brent_3d) from Alleyne Studio for inspiring me to create this because of his old Blender Lightwave/Modo config he made back in the day for 2.7x. His config not only was a source of inspiration for me, but it served as a point of reference for how to create some of the functions in Blender to work like Modo. I would have never made this without him!

And another huge shout out to Vaughan Ling (@Heavypoly) from HEAVYPOLY for creating the Border_Select_Through script in his Blender Config that I used as the base for the Lasso Select variant in my config. I wouldn't have been able to create this without him!

$
